Illustrate | parameter |
Rated voltage | 15KV |
Rated current | 630A |
1 minute power frequency withstand voltage | 42KV |
Lightning impulse withstand voltage | 95KV |
DC withstand voltage | 52KV 15min |
Minimum corona onset voltage | 11KV |
24 hours overload | 1000A |
Short-time withstand current | 25KV/0-17s 10KV/3S |
Illustrate | parameter |
Rated voltage | 15KV |
Rated current | 630A |
1 minute power frequency withstand voltage | 42KV |
Lightning impulse withstand voltage | 95KV |
DC withstand voltage | 52KV 15min |
Minimum corona onset voltage | 11KV |
24 hours overload | 1000A |
Short-time withstand current | 25KV/0-17s 10KV/3S |
Illustrate | parameter |
Rated voltage | 15KV |
Rated current | 630A |
1 minute power frequency withstand voltage | 42KV |
Lightning impulse withstand voltage | 95KV |
DC withstand voltage | 52KV 15min |
Minimum corona onset voltage | 11KV |
24 hours overload | 1000A |
Short-time withstand current | 25KV/0-17s 10KV/3S |
